Connecting to your Onvif IP camera*
Try the following connection options in iSpy or Agent to connect to your Onvif IP camera. If an FFMPEG option is available we recommend you try that first as it will often be faster and include audio support. You can also try the VLC plugin if the FFMPEG option isn't working.
The settings for Onvif cameras are built right into our free surveillance software - click 'Add' then 'IP camera with wizard' to automatically setup your Onvif cameras. Remember to also try connecting via ONVIF as Onvif cameras may support ONVIF connections as well.
Start typing in the 'Make' box to find your camera. If your camera is not listed then click 'Get Latest List' in settings or when on the add camera wizard. If you need to modify the URL then add or edit the Onvif camera and you can modify the connection type and URL in the video source dialog (button is top of the first tab).
Onvif compatible software*
Library implementing client ONVIF for Windows, Linux, Mac LIBONVIF Connects Your Program to IP Camera libonvif is an open source project that implements client ONVIF for communicating with compatible IP. ONVIF Device Manager v2.2.250 I am using ONVIF DM to check connectivity externally to a camera feed from our internal network. As recommended in the setup instructions for the Bridge Server, the server. ONVIF Device Manager is a Network Video Client (NVC) to manage Network Video Transmitters (NVT), Network Video Storage (NVS) and Network Video Analytics (NVA) devices. Thus you need to set up via computer with Reolink client and Onvif device manager. You may follow the steps below to add Reolink cameras to Onvif Device Manager.
Tip: Click a model to generate a URL for your camera
| Models | Type | Protocol | Path |
|---|---|---|---|
| 001111, 23344, 380, 3805P, 3851, 4312B, 57ii, Cotier_TV631W-ip, d53m02, DONPHIA, Euronet, GW5050IP, ipc6200, IPD-E2A5L18-BS, Jidetech, m2-p488, Main, NAUM, NAUM2, NAUM3, ONVIF CAMERA, ONVIF_IPNC, Other, patton, PROVISION ISR, SC3V-1, techma, TH32E-ONVIF, V380, v380 pro, V380-Q10 | FFMPEG | rtsp:// | /mpeg4 |
| 342, 5MPtopsee, 5MPTOPSEE, 960p, 960Pchina spot 2019, d53m02, diamond, gw security 5mg, gwsecurity 5mb, ipc6200, IPC-F20M, IPD-E2A5L18-BS, JH720e1, LBH30SE200W4, lsvision, model 2000, ONVIF_IPNC, Other, rhbr, Secureye, westmile, zsvdr | FFMPEG | rtsp:// | /mpeg4cif |
| 5MPTOPSEE, Other, VNcam | MJPEG | http:// | cgi-bin/video.cgi?msubmenu=mjpg |
| 9411, DomeCam, eyeonet4k, Other, PROVISION ISR, Sibell IP, Techson S1Pro52030IM, tvt | FFMPEG | rtsp:// | /profile1 |
| AK-HD54F245, gate 1, granstream, MC400L, NDR-405-P-BGZ20, oma, ONVIF_IPNC, Other, PTXDome1, PTZ, S3VC, sc3v, SV-B06POE-1080P-A, V380 | FFMPEG | rtsp:// | /stream0 |
| DOMECAM, IPC, Other, PTZ | FFMPEG | rtsp:// | /0 |
| DOMECAM, IPC-model, Other, Other_onvif, profile s, SC3V-1, VESKYS | JPEG | http:// | snap.jpg?JpegCam=[CHANNEL] |
| Ipc | FFMPEG | rtsp:// | /profile2 |
| ipc2122 | FFMPEG | rtsp:// | /h264_stream |
| IPC-HDBW4431R-ZS, IPHD, Other, PTZ | JPEG | http:// | cgi-bin/snapshot.cgi?chn=[CHANNEL]&u=[USERNAME]&p=[PASSWORD] |
| MC400L | JPEG | http:// | cgi-bin/snapshot.cgi?loginuse=[USERNAME]&loginpas=[PASSWORD] |
| Model S, Other, v380, V380 | VLC | rtsp:// | live/ch00_0 |
| NLISTED, Other | JPEG | http:// | snapshot.jpg?account=[USERNAME]&password=[PASSWORD] |
| ONVIF Camera | JPEG | http:// | cgi-bin/CGIProxy.fcgi?cmd=snapPicture2&usr=[USERNAME]&pwd=[PASSWORD] |
| Other | JPEG | http:// | cgi-bin/CGIProxy.fcgi?cmd=snapPicture2&usr=[USERNAME]&pwd=[PASSWORD]& |
| Other, TH38M-ONVIF-P2P | MJPEG | http:// | videostream.cgi?user=[USERNAME]&pwd=[PASSWORD]&resolution=32&rate=0 |
| Other | FFMPEG | rtsp:// | /cam/realmonitor |
| Other, Other, Profile S, PTZ, SC3V-1 | JPEG | http:// | tmpfs/auto.jpg |
| Other | JPEG | http:// | snapshot.jpg?user=[USERNAME]&pwd=[PASSWORD] |
| PTZ, PTZ1, YN-AJ8079R-POE | FFMPEG | rtsp:// | /stream1 |
| QD900, V380 | FFMPEG | rtsp:// | /live/0/MAIN |
| Shenzhen Jiaxinjie Technology Co. Ltd | FFMPEG | rtsp:// | h264 |
| TH38M-ONVIF-P2P, VESKYS | JPEG | http:// | img/snapshot.cgi?size=2 |
| Veskys | FFMPEG | rtsp:// | /tcp/av0_0 |
| Weird | FFMPEG | http:// | videostream.asf?usr=[USERNAME]&pwd=[PASSWORD] |
* iSpyConnect has no affiliation, connection, or association with Onvif’s products. The connection details provided here are crowd sourced from the community and may be incomplete, inaccurate or both. We provide no warranty that you will be successful using these connection URLs or that Onvif products are compatible with iSpy.
